VSUN 3KVA Online UPS Specs: VA Rating: 3kva Real Power Rating: 2400 Watt

• input:
  • Voltage Range: Half -Load 120 -300VAC, Full -Load 165V 300VAC
  • Frequency: 45.5Hz ~ 54.5H
  • Power Factor: >0.95

  Output:

  • Voltage: 220/230/240V ± 3%
  • Waveform: True Sine wave
  • Frequency: 50/60Hz ± 0.5
  • Distortion: < 3% (linear Load); <5% (Non -linear Load)
  • Crest Factor: 3:1
  • Efficiency: 85%
  • Overload Capacity: 110%-150%:Switch to Bypass after 1min; >150%:Shutdown afte r 200ms
  • Short Circuit: UPS output turn off and alarm

  Battery:

  • 6 x 9 AMP Batteries
  • Model: 12V Sealed Lead -Acid
  • Recharge 90% Capacity after 8 Hours charging

• 1 year warranty on ups 3 months on battery
